3 Axle Box Semi Trailer

3 Axle Box Semi Trailer

ZW Group 3 Axles Box Semi Trailer is built for high-capacity trunk-line logistics, e-commerce delivery, and intercity freight. Its enclosed cargo body provides weather protection, theft prevention, and efficient volumetric loading for sensitive goods. Weatherproof construction, secure locking systems, and custom dry van designs help reduce downtime and improve fleet efficiency on long-distance routes.
Get a quote

3 Axle Box Semi Trailer | Heavy-Duty Dry Van Trailer for Secure Freight Transport

3 Axle Box Semi Trailer

Technical Specifications

ParameterSpecification Details
Trailer Type3 Axles Box Semi Trailer / Dry Van Trailer
Rated Capacity40,000 kg to 60,000 kg (Customizable up to 80T)
Overall Dimensions13,500 mm × 2,500 mm × 4,000 mm (Customizable)
Main Beam StructureHigh-tensile Q345B steel, heavy-duty submerged arc welded
Cargo Box MaterialHigh-strength cold-rolled corrugated steel plates
Inner FrameworkReinforced with X-type internal structural braces
Axle Configuration3 units × 13T / 16T premium brands (FUWA / BPW options)
Suspension SystemHeavy-duty mechanical leaf spring or advanced air suspension
Braking SystemWABCO dual-line pneumatic braking valve with optional ABS
Tire Specification12 units × 12R22.5 premium radial tubeless tires
Landing GearJOST 28T dual-speed heavy-duty landing legs
Kingpin SizeJOST 2.0-inch (50#) or 3.5-inch (90#) interchangeable
Roof ConfigurationClosed, push-open, fully open, or tarpaulin pole types
Surface FinishAutomated shot blasting and anti-corrosion marine coating


3 Axle Box Semi Trailer

Main Features

  • Fully enclosed cargo body protects cargo from weather, dust, and theft during transportation.

  • Reinforced high-strength steel chassis provides reliable load-bearing performance and long service life.

  • Rear swing doors and optional side doors enable faster forklift loading and unloading.

  • Mechanical or air suspension options improve driving stability for different road conditions.

  • Custom configurations are available, including body size, flooring, suspension, axle brands, and paint to meet specific logistics applications.

Available Configurations

  • Axle Options: 2 axles, 3 axles, or 4 axles tailored to regional gross vehicle weight rating (GVWR) requirements.
  • Length Variations: Standard 12.5 meters, 13 meters, 40ft, 45ft, and 53ft custom dimensions available based on fleet capacity needs.
  • Suspension Systems: Heavy-duty mechanical leaf spring suspension, single-point bogie suspension, or premium air suspension for sensitive cargo.
  • Premium Axle Brands: Industry-trusted FUWA, BPW, or specialized ZY heavy-duty axles depending on customer maintenance preferences.
  • Tire Configurations: 11.00R20, 12.00R20, 12R22.5 tubeless tires, or 1200/24 off-road tires configured with single or dual-tire setups.

Why Choose ZW Group

  • Factory-Direct Advantage: As a direct box semi trailer factory with a 50,000m2 facility, we eliminate middleman markups to provide superior cost performance.
  • Full OEM/ODM Customization: Our experienced engineering team develops custom dry van trailer configurations tailored exactly to your unique cargo and terrain challenges.
  • Extensive Export Experience: With over 10 years of international trade, ZW Group has successfully delivered premium logistics transport trailer units to 60+ countries worldwide.
  • Comprehensive Lifetime Support: Enjoy peace of mind with 24/7 technical support, rapid spare parts availability, and streamlined global customs and shipping logistics guidance.

Factory Show

3 Axle Box Semi Trailer

Transportation

  1. Bulk cargo, without dismantling any components, shipped as a whole. Advantage: Moderate price, complete shipment, but the product is susceptible to seawater erosion.
  2. Container transportation is cheap and can effectively protect machinery during transportation. But to disassemble the machinery,you need to assemble it yourself after receiving the goods.
  3. Frame container transportation is similar to container transportation, but frame containers can transport ultra-high machinery.
  4. Ro-ro transportation. The product is in the cargo hold and has strong protection, but the price is expensive.
3 Axle Box Semi Trailer

FAQ

A:

A box semi trailer, also known as a dry van semi trailer, is designed for fully enclosed transportation of cargo. It is widely used for high-value, fragile, or weather-sensitive goods such as electronics, packaged consumer products, textiles, food products, and general freight that requires maximum protection during transit.

A:

The biggest advantage of a box semi trailer is full cargo protection. The enclosed structure prevents rain, dust, theft, and external damage. It also provides better security compared to open trailers, making it ideal for long-distance and cross-border logistics where cargo safety is a priority.

A:

Box semi trailers are suitable for palletized goods, carton-packed products, household items, retail goods, and industrial components. They are commonly used in e-commerce logistics, supermarket distribution, and factory-to-warehouse transportation where clean and secure delivery is required.

A:

Yes. Box semi trailers can be customized according to different business requirements. Options include internal dimensions, axle configuration, suspension system, door types (rear door or side door), floor reinforcement, ventilation systems, and insulation panels for temperature-sensitive cargo.

A:

Box semi trailers are typically built with high-strength steel frame structures and aluminum or steel panels for the box body. The internal floor is reinforced to handle heavy pallet loads, while anti-corrosion coating is applied to extend service life under frequent loading and unloading operations.
